Field suitability and speed in one!
- Load volume from 45 - 52m3 DIN
- 30 tonnes permissible total weight
- Permitted speed 60, 65 oder 80 km/hTandem version with self-steering
- Operation via control units, ISOBUS or wireless control
- Saddle plate with fifth wheel height 135 - 150 cm
- Optional: Follow-up control scraper floor/tailgate, load compartment cover
Maximum stability
The side wall structure
The CARGOS achieves maximum stability thanks to the sophisticated conical side wall structure and clever force distribution management.
Laser-welded tipper drop sides over the entire length of the trailer offer maximum stability and ideal force distribution. A perforation in the upper body enables optimum fill level control.
The CARGOS offers narrow stanchion spacing.
The rear lid enables the loading of 3 x 90 square bales and offers a precisely adjustable opening.
Drive power & zinc - strong on both sides
The scraper floor
Galvanised guide rails, galvanised and bolted scraper floor rails for easy replacement of defective rails.
Heavy-duty and tear-resistant galvanised scraper floor chains guarantee extreme durability
- 3 mm thick floor plates
- Mechanical chain tensioners easily accessible on the trolley
NEW - specially designed hydraulic motor
- Double-sided scraper floor drive on all CARGOS
- Strong scraper floor gearbox with two-stage design as standard
Stage 1 - slow, powerful unloading for extremely wet loads
Stage 2 - fast unloading in rapid traverse
- Reverse travel scraper floor possible, e.g. for bale transport
